AS2047 Vinyl Window, UPVC Passive House windows, Double Glazed, Wind Resistance, For Living Room

AS2047 Vinyl Window, UPVC Passive House windows, Double Glazed, Wind Resistance, For Living Room

AS2047 Vinyl Window, UPVC Passive House windows, Double Glazed, Wind Resistance, For Living Room
AS2047 Vinyl Window, UPVC Passive House windows, Double Glazed, Wind Resistance, For Living RoomAS2047 Vinyl Window, UPVC Passive House windows, Double Glazed, Wind Resistance, For Living RoomAS2047 Vinyl Window, UPVC Passive House windows, Double Glazed, Wind Resistance, For Living RoomAS2047 Vinyl Window, UPVC Passive House windows, Double Glazed, Wind Resistance, For Living RoomAS2047 Vinyl Window, UPVC Passive House windows, Double Glazed, Wind Resistance, For Living Room
CategoriesUPVC Passive House Windows
BrandROPO Custom Door and Window Solutions
ModelUPVC Passive House Window 001
Profile ColorWhite / Woodgrain Color
Profile BrandGerman VEKA / Chinese Zhongcai
HardwareGerman ROTO
GlassSingle / Double / Triple / Laminated / Low E
ScreenFixed Screen
FOB portFuzhou / Xiamen
Terms of PaymentL/C, T/T
Update TimeDec 31,2024
Contact Now
Favorites
Detail Information
Product Introduction


Passive House


 Window

Passive house windows have been a popular choice of window in many countries for some time. There are many advantageous properties of tilt and turn windows that explain this success. Typically a quarter turn of the lever will allow the window to swing inwards like a casement window. A second quarter turn will allow the window to tilt inwards from the top.

  • 450Pa

    Water Pressure

  • 4000Pa

    Ultimate Wind Pressure

  • 1.7

    U Value

  • 0.28

    SHGC Value
ROPO UPVC Tilt and Turn Window
Product Video

Flexible Ventilation:

Passive house window offer a great deal of flexibility when it comes to ventilation. You don’t need to have the window fully open to let air into your house, you can open it by tilting. The design also means that when it rains water is prevented from entering your home because of the tilted angle.

Easy Use:

Because passive house windows can swing into the home, it’s really easy to clean both the inside and outside without having to use a ladder for upstairs windows or take the risk of leaning outside your window. They are also easy to open and close as the window opens inwards and not outwards.

Safety and Security:

Passive house window style is particularly suitable for family homes with small children. You’ll still be able to ventilate the house without the danger of children falling out or getting fingers trapped. Also, as these windows can be opened fully they could provide a fire escape in the event of an emergency.

Product PDF
UPVC Passive House Drawing Section
UPVC Passive House Window Intertek Report
Product Details Map
ROPO UPVC Tilt and Turn Window Corner details
Colored Profile :

RENOLIT high-performance films for UPVC profile exterior applications to make the window finish look like solid wood.
Corner Sample :

Multi-chambered frame and sash extrusions for super strength and insulating properties

Reinforcement steel inside the chamber for supporting.

Lead free profile- Energy saving and UV protection.
ROPO UPVC Tilt and Turn Window Corner details
ROPO UPVC Tilt and Turn Window Hardware Details
Hardware :

Heavy duty hinge with 304 stainless steel for maximum durability.
Multi-point stainless steel locking device for enhanced security.
Possible Passive House Window Configurations :

Tilt and Turn window can be designed with fixed window combined.
One panel tilt and turn window opening width should be limited in 1200mm, the window height is better smaller than 1800mm for maximum using experience and durable.
If the tilt and turn window width bigger than 1200, we suggest double panel in tilt and turn or one panel tilt and turn with fixed panel.

ROPO UPVC Tilt and Turn Window Possible Configurations
Glass Should Be Selected On The Basis Of Thermal Insulation Requirement, Sound Insulation Requirement And Safety Requirement.
Click to jump
The color should be selected according to the customization requirements, click to jump to the color interface
Click to jump
