Aluminum Frame Hinged Swing Door, Double Glazed Casement Door, Soundproof, French Style, For Bedroom, Entrance

Aluminum Frame Hinged Swing Door, Double Glazed Casement Door, Soundproof, French Style, For Bedroom, Entrance

Aluminum Frame Hinged Swing Door, Double Glazed Casement Door, Soundproof, French Style, For Bedroom, Entrance
Aluminum Frame Hinged Swing Door, Double Glazed Casement Door, Soundproof, French Style, For Bedroom, EntranceAluminum Frame Hinged Swing Door, Double Glazed Casement Door, Soundproof, French Style, For Bedroom, EntranceAluminum Frame Hinged Swing Door, Double Glazed Casement Door, Soundproof, French Style, For Bedroom, Entrance
CategoriesAluminum Casement Doors
BrandROPO Custom Door and Window Solutions
ModelAluminum Casement Doors 001
Profile ColorWhite / Black / Grey / Customized Color
Profile BrandJMA 6063-T5
HardwareGerman ROTO / Cmech
GlassSingle / Double / Triple / Laminated / Low E
ScreenAccordion Screen / Security Screen
FOB portFuzhou / Xiamen
Terms of PaymentL/C, T/T
Update TimeNov 21,2024
Contact Now
Favorites
Detail Information
Product Introduction
Casement Doors

Aluminum casement doors is the door type that use a wide range now. It is means the door that hinges installed at one side of door leaf, then the door open inside and outside. It is composed of door frame, hinges and door leaf ect.

  •  600Pa

    Water Pressure

  •  1600Pa

    Ultimate Wind Pressure

  • 2.6

    U Value

  • 0.34

    SHGC Value
Double Glazed Soundproof Aluminum Hinge Casement Door
Product Video

Light Weight:

When compared to hinges made of other materials, aluminum hinges are lightweight. Most aluminum hinges, for instance, weigh about one-third the weight of their stainless steel counterparts. With their lightweight properties, they are easy to install and remove.

Corrosion Resistant:


Aluminum hinges are also resistant to corrosion. They can withstand humidity and moisture without succumbing to oxidation. Aluminum is actually immune to rust. aluminum hinges can’t rust. At the same time, they are highly resistant to other forms of corrosion. Their corrosion-resistant properties make aluminum hinges ideal for exterior doors.

Inexpensive:

aluminum hinges often cost less than hinges made of other materials. Because of its recyclable properties — along with the fact that aluminum is an abundant metal — aluminum hinges are inexpensive.

Product PDF
Aluminum Casement Doors Drawing Section
Aluminum Casement Doors Intertek Report
Product Details Map
Corner Profile :

Multi-chambered frame, JMA Window System (http://www.jma.cn/en/index.php ), 6063-T5, and The Powder Coating is from German Interpon (AkzoNobe Group) (https://www.interpon.com/cn ) for UV resistance. 10 Years Warranty.
Double Glazed Soundproof Aluminum Hinge Casement Door Corner Profile
Double Glazed Soundproof Aluminum Hinge Casement Door Details
Details :

1, Silicon Sealant-U.S.A Brand DOW CONING
2, Glass Bead- All glass sealed by glass bead, not silicone. so if the glass is broken, it is easy to change.
3, Rubber strip is EPDM for good sealent and 10 years warranty.
4, All screwn is stainless steel to resist corrosion

Double Glazed Soundproof Aluminum Hinge Casement Door Hardware
Hardware :
Heavy duty hinge with 304 stainless steel for maximum durability.
Multi-point stainless steel locking device for enhanced security.
Double Glazed Soundproof Aluminum Hinge Casement Door Configurations
Possible Casement Doors Configurations :

One panel casement door opening width should be limited in 1200mm, the door height is better smaller than 2700mm for maximum using experience and durable.
If the casement door width bigger than 1300mm, we suggest double panels style or one panel with fixed.
Glass Should Be Selected On The Basis Of Thermal Insulation Requirement, Sound Insulation Requirement And Safety Requirement.
